• Load capacity up to 900 kg
• Lightweight portable design for mounting into utes, service bodies, vans, loading docks, platforms etc
• Allows for 1 person to easily lift engines, watercraft and more
• 360 degree swivel design allows for maximum accessibility
• Rugged heavy-duty construction ensures long term durability
• Swivel crane hoist’s boom extension locks in 2 positions (1000lbs and 2000lbs)

Perfect tool for landscapers, tree surgeons, builders and farmers lifts up to a maximum 3000lb with the wire cable winch.

The crane is extremely versatile for many lifting situations – with the crane being detachable from the base for security reasons. It can even be mounted on your van or trailer body to allow the easy on/off lift of heavy items.

The uses for this fantastic crane are endless. A local tree surgeon has his mounted in the center of his trailer allowing him to load bulk bags of logs and the other at the headboard of his tipping van body allowing him to lift heavy equipment on and off by himself.

The swivel crane hoist has a small footprint, with a base that only takes up 270 mm x 270 mm of space.

SPECIFICATIONS:

• Color: Black
• Material: Steel
• Type: Electric hoist crane
• Lifting capacity (maximum): 900kg
• 2-stage adjustable load arm: 1000/2000 LBS
• Power requirement: 12VDC
• Lifting height (Base to hook): 1785mm
• Storage height folded (from base): 1350mm
• Lifting cable: 6 metre (length) x 5mm (thickness)
• Mounting Base: 270mm x 270mm
• Electric Winch (Single Cable): Max 450kgs
• Electric Winch (Double Cable): Max 800kgs
• Hydraulic Pump: Max 900kgs
• Weight: 58 kg

IN THE BOX

1 – Pickup Crane set

1 – Electric Winch

1 – Manual
